AR+ woodscrew, partial thread, outdoor, torx
Vajuta pildi suurendamiseks
Kirjeldus
Puidukruvid: suurepärasteks puit puitu kinnitamiseks.
- Harmonized standard EN 14592:2008+A1:2012
Andmed
Identifitseerimine
- Article number
- 33018060120
- GTIN
- 8715274244815
Tehnilised andmed
- Wire material
- Carbon steel standard tensile
Kinnitusdetailide spetsifikatsioonid
- Finish
- Weatherex III
- Application environment
- Outdoor
- Point type
- Sharp w/ milling threads
- Screw head type
- Countersunk with nibs
- Screw recess
- Torx 30
- Screw thread type
- Partly threaded
- Screw length
- 120.0 mm
- Screw diameter
- 6.0 mm
CE spetsifikatsioonid
- Characteristic head pull through parameter
- 14.0 N/mm²
- CE fastener type
- All Round Wood Screw
- DOP No
- 33018060120
- Threaded/profiled length
- 72.0 mm
- Characteristic yield moment
- 9600.0 Nmm
- Torsional ratio
- ≥1.5
- Characteristic torsional strength
- 9.5 Nm
- Characteristic tensile capacity
- 11000.0 N
- Harmonized standard
- EN 14592:2008+A1:2012
- Characteristic withdrawal parameter
- 10.0 N/mm²
Mittetehnilised andmed
- Package quantity
- 100
Logistilised spetsifikatsioonid
- Net weight
- 1.48 kg
